Start of Production |
2002 |
Click to View |
|
End of Production |
N/A |
|
|
Numbers Produced |
N/A |
|
|
Price (2003) UK £ |
7,295 |
|
|
US $ |
10,790/12,990 with ABS |
|
|
Engine |
|
|
|
Motor Type |
Four-stroke, two cylinder, horizontally opposed "Boxer" engine, air cooled |
|
|
Bore x Stroke |
101 x 70.5 mm (3.97 x 2.77 in) |
|
|
Displacement |
1130 cc |
|
|
Max Power |
85 hp (62.5 KW) at 6,750 rpm |
|
|
Max Torque |
98 Nm / 72 ft lb at 5,250 rpm |
|
|
Compression Ratio |
10.3 : 1 |
|
|
Valves Per Cylinder |
4 |
|
|
Valve Control |
hc, using chain drive, cup tappets, push rod and rocker arm |
|
|
Mixture Control / Engine Management |
Electronic intake pipe injection/digital engine management: Bosch Motronic MA 2.4 with overrun fuel cut off, twin spark ignition |
|
|
Emission Control |
Closed loop 3 way catalytic converter |
|
|
Engine Lubricating System |
Wet sump |
|
|
Power Transmission |
|
|
|
Clutch |
Single disc dry clutch, hydraulically operated |
|
|
Gearbox |
Constant mesh 6 speed gearbox |
|
|
Gearbox Ratios |
2.045 / 1.600 / 1.267 / 1.038 / 0.900 / 0.700 |
|
|
Rear Wheel Ratio |
2.82 |
|
|
Drive |
Shaft Drive |
|
|
Electrical System |
|
|
|
Ignition System |
Electronic ignition, Bosch Motronic MA 2.4. Twin spark |
|
|
Alternator |
700 W three phase alternator |
|
|
Battery |
12V / 19 Ah |
|
|
Chassis |
|
|
|
Type of Frame |
Three section composite frame consisting of front & rear section, load bearing engine |
|
|
Front wheel suspension |
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut, rebound damping adjustable |
|
|
Rear wheel suspension |
Die cast aluminium single sided swinging arm with BMW Motorrad Paralever; central strut, spring pre-load adjustable to continuously variable levels by mean of a hydraulic handwheel, rebound adjustable damping |
|
|
Travel Front/Rear |
120 / 135 mm (4.72 / 5.31 in) |
|
|
Wheels |
Die cast aluminium wheels |
|
|
Wheel Rims, Front |
3.50 x 17 |
|
|
Wheel Rims, Rear |
5.50 x 17 |
|
|
Tyres, Front |
120 / 70-ZR 17 |
|
|
Tyres, Rear |
180 / 55-ZR 17 |
|
|
Brakes, Front |
EVO brake system with dual disc, floating brake discs, diameter 320 mm / 12.6 in, 4 piston fixed caliper |
|
|
Brakes, Rear |
Single disc brake 276 mm / 10.86 in diameter, double piston floating caliper |
|
|
ABS |
Special equipment BMW Motorrad Integral ABS (partially integral) |
|
|
Dimensions/Weights |
|
|
|
Length x Width x Height |
2170 x 920 x 1097 mm (85.43 x 36.22 x 43.18 in) |
|
|
Seat Height |
835 mm / 32.87 in (special equipment low seat bench: 795 mm / 31.29 in) |
|
|
Wheel Base |
1486 mm / 58.50 in |
|
|
Castor (in Normal Position) |
125 mm / 4.92 in |
|
|
Steering Head Angle (in Normal Position) |
63.1 degrees |
|
|
Fuel Tank Useable Volume |
20.5 litres / 4.50 gal / 5.41 gal US |
|
|
Reserve |
4.0 litres / 0.87 gal / 1.05 gal US |
|
|
Unladen Weight with Full Tank |
239 Kg / 526 lb |
|
|
Dry Weight |
219 Kg / 482 lb |
|
|
Max. Permissible Weight |
450 Kg / 991 lb |
|
|
Payload (with Standard Equipment) |
211 Kg / 464 lb |
|
|
Fuel Consumption over 100 Km @ constant 90 Kph |
4.6 litres / 61 mpg / 51 mpg US |
|
|
Fuel Consumption over 100 Km @ constant 120 Kph |
5.7 litres / 49 mpg / 41 mpg US |
|
|
Fuel Type |
Unleaded Premium minimum octane rating 95 (RON) |
|
|
Top Speed |
Approx. 197 Kph / 122 mph |
|
