Start
of Production |
1936 |
Click to View |
|
End of
Production |
1936 |
|
Number
Produced: |
740 |
|
Price: |
995
RM |
|
Engine |
|
|
Internal Designation |
203/1 |
|
Motor Type |
Four
Stroke single cylinder vertical |
|
Bore
x Stroke |
68 x
84 mm (2.67 x 3.30 in) |
|
Displacement |
305
cc |
|
Maximum Power |
11hp
at 4,200 rpm |
|
Compression Ratio |
6.0 :
1 |
|
Valves |
OHV |
|
Carburation System |
1 x
register carburettor SUM type CK 3/500 |
|
Engine Lubricating System |
Forced Feed Lubrication |
|
Oil
Pump |
Gear
Pump |
|
|
|
Power
Transmission |
|
|
Clutch |
Single plate dry clutch |
|
Number of Gears |
4 |
|
Gear
Shift |
Manual |
|
Gearbox Ratios |
3.6 /
2.18 / 1.35 / 1 |
|
Rear
Wheel Ratio |
1 :
5.11 (1 : 5.63 with sidecar) |
|
Bevel
/ Crownwheel |
9 /
46 teeth (8 / 45 with sidecar) |
|
|
|
Electrical System |
|
|
Ignition System |
Battery ignition |
|
Generator |
Bosch
6V/45/70 W |
|
Spark
Plugs |
Bosch
W 175/T1 |
|
|
|
Chassis |
|
|
Designation |
203/1 |
|
Frame |
Pressed steel twin loop frame |
|
Front
Suspension |
Cantilever spring, 9 laminae with friction shock absorber |
|
Rear
Suspension |
Rigid |
|
Wheel
Rims |
2.5 x
19 |
|
Front
Tyre |
26 x
3.5 balloon |
|
Rear
Tyre |
26 x
3.5 balloon |
|
Front
Brakes |
Drum
brake |
|
Rear
Brake |
Drum
brake |
|
|
|
Dimensions/Weights |
|
|
Length x Width x Height |
1980 x 850 x 950 mm
(77.95 x 33.46 x 37.40 in) |
|
Wheel
Base |
1320
mm / 51.96 in |
|
Fuel
Tank Capacity |
12
litres / 2.63 gal / 3.17 gal US |
|
Unladen Weight with full tank |
149
kg / 328 lb |
|
Permitted Weight Limit |
200
kg / 440 lb |
|
Fuel
Consumption |
3 litres per 100 kilometres approx
/ 94 mpg / 78 mpg US |
|
Oil
Consumption |
1 -
2 litres per 1,000 kilometres |
|
Top
Speed |
100 kph
/ 62 mph |
|
|
